JG MAKER Industrial SLA 3D Printer JG-A600 Large Print Volume Up to 23.6×22.8×14.9in High Accuracy

Price: $29,999.00
(as of May 20,2023 15:22:59 UTC – Details)

Product Description

JG MAKER SLA-600 Industrial Grade 3D Printer 23.6×22.8×14.9in

Experience an exceptional 3D printing experience with the JG MAKER SLA-600 Industrial Grade 3D Printer. With a large build volume of up to 23.6×22.8×14.9in, it allows you to create large and complex designs with high accuracy. It uses pulse, ultraviolet, full solid state laser with a wavelength of 354.7nm and has a watt of 3W (100KHz) with full vacuum adsorption coating spread method. The standard layer thickness is 0.1mm, with quick speed layer thickness of 0.1-0.2mm and precision layer thickness of 0.05mm.

The JG MAKER SLA-600 can achieve vertical accuracy of ±0.008mm and repeatability of ±0.015mm. The max per unit print weight is 176Lbs and the resin tank volume is approximately 230L (557Lbs) with wraparound silicone plate heating wire heating resin tank heating method.

Operation System

The operation system of the JG MAKER SLA-600 is Windows 7, with JGSLA3D as its operating software. You can upload file formats of SLC and connect via the internet. It requires power of 200-240V AC50/60Hz 12A, with a condition temperature set at 20-28℃ and humidity of <40%. The machine dimensions are 51.1(L) x51.(W) 74.8(H) IN and machine weight is approximately 2866Lbs.

Variable Spot Technology
