Overview of YFQHDD 8-Port Desktop Gigabit Switch

Price: $355.03

(as of May 21,2023 19:39:08 UTC – Details)

This YFQHDD 8-Port Desktop Gigabit Switch is designed to increase the forwarding rate of large files with its 8 10/100/1000Mbps auto-negotiation port. The switch automatically identifies parallel/crossing lines, making network installation and maintenance easier. It also ensures smooth network applications with gigabit non-blocking wire-speed forwarding and full-duplex flow control as well as half-duplex back pressure control to prevent frame loss caused by port blocking. The switch adopts store and forward mode and has an integrated 4K address table. It supports 9K frames, which increases the forwarding rate of large files. Made of natural green environmental protection ABS material, this switch has high fire rating and good heat dissipation performance. The switch supports network surveillance camera access, ensuring clear and uninterrupted picture quality. It also supports desktop/wall-mounted design for easy installation.

Specification:

• Hardware
  • Network standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE802.3ab
  • LED indicator: 1 * power, 8 * link/action
  • Interface: 8 * 10/100/1000 Base-T Ethernet port (Auto MDI / MDIX)
  • Transmission media: Recommended: CAT5 / 5e UTP or higher
  • NuMBer of fans: no
  • Product size: 142x90x24mm
  • Material: Plastic
  • Exhaust volume: ±8kV
  • Contact discharge: ±6kV
  • Forwarding mode: store and forward
  • Switching capacity: 16Gbps
  • Packet forwarding rate: 12 per second
  • Buffer: 2MB
  • address table: 4K
  • JoMBo frame: 9K
• Power supply
  • Input: 100-240V AC 50 / 60Hz
  • Output: 9V 0.6A (external power adapter)
  • Power consumption: Maximum: <;4W
• Installation
  • Desktop installation: support
  • Wall-mounted: support
  • Rack installation: not supported
• Environment
  • Working temperature: 0°C-45°C
  • Storage temperature: -40°C-70°C
  • Working humidity: (10%-90%) RH, non-condensing
  • Storage humidity: (5%-90%) RH, no condensation
• Certificate: CE, FCC, RoHS
• Software
  • Protocol: CDMA / CD
  • address learning: automatic learning and automatic aging

Note: There mi
